12W Integrated Solar Street Light System
Product Details:
12W Integrated Solar Street Light System Price And Quantity
- 50 Piece
- 12650 INR/Piece
12W Integrated Solar Street Light System Trade Information
- 20 Piece Per Day
- 2 Days
- All India
Product Description
12W Integrated Solar Street Light System
| Usage/Application | Garden, Park, Road, etc |
| Brand | Rudra |
| Lighting Type | LED |
| IP Rating | IP65 |
| Load Power (Wattage) | 15W |
| Dimension | 655 x 400 x 42mm |
| Frequency | 50-60Hz |
| Maximum Lumens | 4500 Lumen |
| Battery Capacity | 14.8V, 10.4AH , 300Wh |
| Battery Type | Li-ion, LiFePO4 |
| Body Material | Aluminum |
| Color Temperature | 6000 - 6500k |
| Temperature range | 0 to 60 Degree |
| Humidity range | 0 to 95 % |
| LED Driver Efficiency | Above 92 % |
| LED Chip | Osram Oslon |
| Solar PV Module | 75wp mono-crystalline |
| Solar Panel MPP Voltage | 19 volt |
| Motion Sensor Type | Passive Infrared Sensor |
| Sensor Working Range | 12 meters |
| Sensor Angle | 102 degree horizontal, 92 degree vertical |
| PWM Frequency | LED driver: 30.53 KHz, Charge controller: 25 Hz |
| Light Mounting Height | 4 meter above ground level |
| Current Consumption | Less than 2 ma |
Specifications:
| Product name | ETSSLAIO-15-ECO [Li-ION] | ETSSLAIO-15-PRM [LiFePO4] |
| - | - | - |
| LED chip | OSRAM OSLON | OSRAM OSLON |
| Solar PV module | 75wp mono-crystalline | 75wp mono-crystalline |
| Solar panel MPP voltage | 19 volt | 19 volt |
| Battery type and capacity | Li-ION - 300Wh | LiFePO4 - 300Wh |
| Motion sensor | Passive Infrared Sensor - 12 meters working range, Detection: 102 degree horizontal 92 degree vertical | Passive Infrared Sensor - 12 meters working range, Detection: 102 degree horizontal 92 degree vertical |
| Lumen output | 4500 Lumen | 4500 Lumen |
| Secondary optics | Yes | Yes |
| LED driver efficiency | > 92 % | > 92 % |
| LED driver methodology | Dual PWM dc-dc buck converter | Dual PWM dc-dc buck converter |
| Charge controller methodology | Three stage battery charge monitoring algorithm | Three stage battery charge monitoring algorithm |
| Ideal current consumption | Less than 2 ma | Less than 2 ma |
| PWM frequency | LED driver: 30.53 KHz Charge controller: 25 Hz | LED driver: 30.53 KHz Charge controller: 25 Hz |
| Light mounting height | 4 meter above ground level | 4meter above ground level |
| Temperature range | 0C to 60C | 0C to 60C |
| Humidity range | 0 to 95% | 0 to 95% |
Price:
- 50
- 100
- 200
- 250
- 500
- 1000+
