9W Integrated Solar Street Light System

Name: 9W Integrated Solar Street Light System
Brand: RUDRA ENTERPRISE
Price: 11100 INR
Availability: InStock

11100 INR/Piece

Get a Price/Quote

Product Details:

Click to View more

Request to Call Back Send Inquiry

Product Details
Product Description

9W Integrated Solar Street Light System Price And Quantity

Minimum Order Quantity 50 Piece
Price 11100 INR/Piece

9W Integrated Solar Street Light System Trade Information

Supply Ability 20 Piece Per Day
Delivery Time 1 Week
Main Domestic Market All India

Product Description

9W Integrated Solar Street Light System

Product Details:

Brand	Rudra
Lighting Type	LED
IP Rating	IP65
Load Power (Wattage)	9W
Frequency	50-60Hz
Maximum Lumens	1170 Lumens
Battery Capacity	14.8V,6.6AH,80Wh
Weight	7.1 Kg
Operating Temperature	0 to 60Deg C
Humidity	0 to 95%
Body Material	Aluminum
Color Temperature	6000 - 6500k
LED Chip	Osram Oslon
Solar PV module	27wp mono-crystalline
Solar Panel MPP Voltage	19volt
Battery Type	Li-ion,LiFePO4
Motion SensorType	Passive Infrared Sensor
Sensor Working Range	12 meters
Sensor Angle	102 degree horizontal,92 degree vertical
LED Driver Efficiency	Above 92 %
PWM frequency	LED driver: 30.53 KHz,Charge controller: 25 Hz
Light Mounting Height	4 meter above ground level

Sp Secifications:

Product name	RESSLAIO-9-ECO [Li-ion]	RESSLAIO-9-PRM [LiFePO4]
LED chip	OSRAM OSLON	OSRAM OSLON
Solar PV module	27wp mono-crystalline	27wp mono-crystalline
Solar panel MPP voltage	19volt	19 volt
Battery type and capacity	Li-ION - 80Wh	LiFePO4 - 80Wh
Motion sensor	Passive Infrared Sensor - 12meters working range, Detection: 102 degree horizontal 92 degreevertical	Passive Infrared Sensor - 12meters working range, Detection: 102 degree horizontal 92 degreevertical
Weight (kg)	7.1 Kg	7.1 kg
Secondary optics	Yes	Yes
LED driver efficiency	> 92 %	> 92 %
LED driver methodology	Dual PWM dc-dc buck converter	Dual PWM dc-dc buck converter
Charge controller methodology	Three stage battery chargemonitoring algorithm	Three stage battery chargemonitoring algorithm
Ideal current consumption	Less than 2 ma	Less than 2 ma
PWM frequency	LED driver: 30.53 KHz Chargecontroller: 25 Hz	LED driver: 30.53 KHz Chargecontroller: 25 Hz
Light mounting height	4 meter above ground level	4 meter above ground level
Humidity range	0 to 95%	0 to 95%
Temp. range	0 degree C to 60 degree C	0 degree C to 60 degree C
