9 Watt Semi Integrated Solar Street Light System

Name: 9 Watt Semi Integrated Solar Street Light System
Brand: RUDRA ENTERPRISE
Price: 7600 INR
Availability: InStock

7600 INR/Piece

Request to Call Back Send Inquiry

9 Watt Semi Integrated Solar Street Light System Price And Quantity

9 Watt Semi Integrated Solar Street Light System

Product Details:

Body Material	Aluminum, MS, Etc
Lighting Type	LED
Pole Height	4.3 meter above ground level
Battery Capacity	14.8V,6.6AH,97.68Wh
IP Rating	IP65
Lumens	1350 Lumen
Humidity	0 to 95%
Color Temperature Range	6000K - 6500K
Brand	Rudra
Working Hour	12
Efficiency	Above 92%
Frequency	LED driver 30.53 KHz, Charge controller 25 Hz
Warranty	2 year
LED Lamp	9 watt
LED Chip	Osram Oslon
Solar PV Module	40wp poly-crystalline
Solar Panel MPP Voltage	19volt
Current Consumption	Less than 2 mA
Temperature Range	0DegC to 60DegC
Product Warranty	2Year, 5Year

Product name	RESSL2IN1-9-ECO [Li-ion]	RESSL2IN1-9-PRM [LiFePO4]
LED lamp	9 watt	9 watt
LED chip	OSRAM OSLON	OSRAM OSLON
Solar PV module	40wp poly-crystalline	40wp poly-crystalline
Solar panel MPP voltage	19volt	19 volt
Battery type and capacity	Li-ION -97.68Wh	LiFePO4 -97.68Wh
Lumen output	1350 Lumen	1350 Lumen
Secondary optics	Yes	Yes
LED driver efficiency	> 92 %	> 92 %
LED driver methodology	Dual PWM dc-dc buck converter	Dual PWM dc-dc buck converter
Charge controller methodology	Three stage battery charge monitoring algorithm	Three stage battery charge monitoring algorithm
Ideal current consumption	Less than 2 ma	Less than 2 ma
PWM frequency	LED driver: 30.53 KHz Charge controller: 25 Hz	LED driver: 30.53 KHz Charge controller: 25 Hz
Light mounting height	4.3 meter above ground level	4.3 meter above ground level
Color temperature	6000K - 6500K	6000K - 6500K
Humidity range	0 to 95%	0 to 95%
Temperature range	0C to 60C	0C to 60C
Product warranty	2 years	5 years
